4CH Analog XLR Audio Over Fiber With Green Standard Terminals

Name: 4CH Analog XLR Audio Over Fiber With Green Standard Terminals
Brand: OptoElectronics
Price: 1 USD

China 4CH Analog XLR Audio Over Fiber With Green Standard Terminals wholesale

Brand Name : OptoElectronics

Model Number : OP-4A-GT

Place of Origin : China

MOQ : 1 pair

Price : Conact us

Payment Terms : T/T

Supply Ability : 1000pair per month

Delivery Time : 8~15working days

Packaging Details : Carton box

Contact Now

4CH Analog XLR Audio Over Fiber With Green Standard Terminals

4CH Audio over fiber with Green standard Terminals

Audio over Fiber series support 1~32 Channel simplex or 16 channel duplex 24-bit digitally encoded broadcast quality audio over one multi-mode or single-mode optical fiber. These fiber optic transmitters and fiber optic receivers are typically used in applications for Rental, Staging, Theater, Stadiums, Theme Parks, Broadcast/Studio, CCTV audio and Professional AV applications, etc, and are available for stand-alone or rack-mount installations. FC, ST, or SC optical connectors is optional.

Plug and Play design ensures adjustment-free installation and operation, and optical adjustments are never required. LED indicators are provided to monitor the system operating status instantly.

Specifications

Opitcal:

Wavelength	1310nm&1470nm~1610nm
Output Power	-14~ -8dBm / -5~0dBm
Optic fiber	50/125u multimode,62.5/125u multimode,9/125u single mode
Rx sensitivity	-30dBm
Optical connector	FC,ST,SC (optional)
Distance	0~2KM (MM) / 0~20KM (SM)

Audio

Input/output Impedance	600ohm(unbalance)
Max input/output voltage	3.0Vp-p
Frequency Response	10 Hz～29kHz @±3dB
SNR	> 70dB
Connector	Standard terminal lead
Number of Channels	1 BIDI

Electrical & Mechanical

Input Power Requirements:	DC 5V@2A
Power Adapter:	AC 90V~240V
Power Consumption:	< 3W
Stand-Alone Dimensions:	104mm × 104mm × 28mm
Shipping Weight:	(include Transmitter & Receiver ) 0.8kg

Environmental

Operating Temperature:	-20°C ~ +75°C
Storage Temperature:	-40°C ~ +85°C
Relative Humidity:	0% ~ 95% (non-condensing)
MTBF:	>100,000 hours
